OMG-OCSMP-MBI300 試験問題を無料オンラインアクセス

Choose the correct answer
Which diagram fragment validly depicts adding properties to a stereotype?

• A.
• B.
• C.
• D.

Choose the correct answer.
Given the model composed of the following diagram:

The modeler has set all shown values us inputs and next intends to solve the mode that is, to calculate the outputs. Assume nothing relevant has been left out.
What is wrong with this model?

• A.Block A cannot be used by both easel and case2.
• B.The slash (/) in property a1 of BlockA is an error that paramethes will assume to be a division sign.
• C.Both easel and case2 should not be underlined.
• D.The modeler set a1 as an input value in case1.

Choose the correct answer
How is a testCase used to validate a requirement?

• A.The testCase model element can be used in SystvIL but it only applies to software
• B.Validation of a requirement can be indicated using a satisfiedBy relationship to a testCase
• C.testCase is part of the UML Testing Profile and cannot be used with SysML.
• D.Only the verdict model element (which can be a property of a testCase) can have a verifies relationship to a requirement.
• E.A requirement can have a vehfiedBy relationship to a testCase even if the test has not yet been conducted or even fully specified

Choose the correct answer.
To "show what you know" about SysML a Systems Engineer (SE) must take a total of four examinations in order Model User (MU). Model Bulkier Fundamental (MBF), Model Builder intermediate (MBI> and Model Builder Advanced (MBA). The SE must also study before taking each exam.
Which activity diagram fragment correctly uses object state constraints to document the process of studying and taking the exams, ensuring that the exams are taken in order of increasing difficulty, and allowing for the possibility that exams may have to be repeated?

• A.
• B.
• C.
• D.

Choose the correct answer
A system consists of two identical tanks each containing a different level of fluid. The tanks are connected together by a port at the bottom of each tank. This system is modeled m the following diagram:

Which statement is true?

• A.The value property /rate : flow rate is a derived property, which accommodates calculating its value based on oilier properties
• B.The block Fluid, which types item property flow 1 ->2. has a value property press : Pressure with a default value of null
• C.Parts t1 and t2 each use part instances to redefine the value of property level : Height
• D.The value of /rate for item property flow 1->2 is positive for flow from t1 to t2. and negative for How in the other direction
• E.Both port p1 on pan t1. and port p1 on t2. must have values defined for value properties /rate and press
