You currently have a FAS8200 with ONTAP 9.5. You want to expand the front end FC I/O capabilities. However, you are unsure which target adapters are supported.
What would you use to confirm which adapters are supported with your current configuration?

• A.Upgrade Advisor
• B.Hardware Universe (HWU)
• C.OneCollect
• D.Interoperability Matrix Tool (IMT)

Exhibit:

Referring to the exhibit, which FC LIF would cause a path failure on a host connecting to a LUN?

• A.fcp_sanluns01prod02p0g
• B.fcp_sanluns0lptodOlp0e
• C.fcp_sanluns01prod02p0g
• D.fcp_sanluns01prod02p0e

Click the Exhibit button.

You have a 2-node cluster in a single-fabric SAN. Host 1 and Host 2 are part of a VMware cluster and access the same LUNs that reside in your NetApp storage.
Referring to the exhibit, what would be a way to test whether the multipathing is properly configured in your environment?

• A.Disconnect Host 1 port and verify whether Host 2 is still able to run the VMs.
• B.Power off the SAN switch.
• C.Administratively set ports 0a and 0c on Controller 1 to the offline setting.
• D.Verify whether all destination storage target ports are contained in the same zone as Host 1.

You create a 20 GB LUN in a newly created 100 GB FlexVol volume. You then write 5 GB of data to the LUN. You have space reservation disabled on the LUN.
In this scenario, how much space do you have left on the volume?

• A.75 GB
• B.80 GB
• C.85 GB
• D.95 GB

You are provisioning a LUN using an ISCSI initiator on an ESX host. You disable Ethernet flow control for all ports but are experiencing Performance issues.
In this scenario, which two actions would improve the performance issue? (Choose two.)

• A.Confirm that your host .mil storage polls are connected to a different network.
• B.Enable jumbo frames across the entire data path.
• C.Set the MTU settings 1500 for optimal performance.
• D.Dedicate your ports to ISCSI traffic.
