You want to advertise only a default route into a new area, which will be called area7.
In this scenario, which configuration statement would solve this problem?

• A.User@host # set protocols ospf area 0.0.0.7 stub no-summaries
• B.User@host t# set protocols ospf area 0.0.0.7 nssa default-lsa default-metric 10
• C.user@host # set protocols ospf area 0.0.0.7 stub default-metric 10
• D.user@host # set protocols ospf area 0.0.0.7 stub

You want to configure Layer 2 services over an IP-based tunneling mechanism between two sites. Which configuration statement is required to accomplish this task?

• A.Set interface ip-00/0/0.0 encapsulation valn-bridge
• B.Set interfaces gr-0/0/0.0 encapsulation vlan-bridge
• C.Set interface gr-0/0/0.0 family bridge
• D.Set interface ip-0/0/0.0 family bridge

Your network connect to the Internet Through two different ISPs using EBGP. You must ensure that ISP1 is the primary path used for all traffic entering your network while using ISP2 as a backup path.
In this scenario, which statement is correct?

• A.You should assign a higher local preference on routers that you are sending to ISP1.
• B.You should use a lower MED value on routes sent to ISP1.
• C.You should your local AS number three times on routes that you are sending to ISP2.
• D.You should change the next hop for all routes sent to ISP2.

Exhibit.

Referring to the exhibit, which configuration will force traffic to always use ae0.0 as long as it is active?

• A.Option D
• B.Option B
• C.Option C
• D.Option A

Which two OSPF header fields must match to form an adjacency over a broadcast connection? (Choose two.)

• A.neighbor
• B.Router priority
• C.Options
• D.Hello interval
