Refer to the exhibit.

Which contains a network diagram and routing table output.
The Student is unable to access Webserver.
What is the cause of the problem and what is the solution for the problem?

• A.The first reply packet for Student failed the RPF check .
  This issue can be resolved by adding a static route to 203.0. 114.24/32 through port3.
• B.The first packet sent from Student failed the RPF check.
  This issue can be resolved by adding a static route to 10.0.4.0/24 through wan1.
• C.The first reply packet for Student failed the RPF check.
  This issue can be resolved by adding a static route to 10.0.4.0/24 through wan1.
• D.The first packet sent from Student failed the RPF check.
  This issue can be resolved by adding a static route to 203.0. 114.24/32 through port3.

Which statement about video filtering on FortiGate is true?

• A.It inspects video files hosted on file sharing services.
• B.Full SSL Inspection is not required.
• C.Video filtering FortiGuard categories are based on web filter FortiGuard categories.
• D.It is available only on a proxy-based firewall policy.

Which of the following statements is true regarding SSL VPN settings for an SSL VPN portal?

• A.By default, the admin GUI and SSL VPN portal use the same HTTPS port.
• B.By default, the SSL VPN portal requires the installation of a client's certificate.
• C.By default, split tunneling is enabled.
• D.By default, FortiGate uses WINS servers to resolve names.

Refer to the exhibits.
Exhibit A shows a network diagram. Exhibit B shows the firewall policy configuration and a VIP object configuration.
The WAN (port1) interface has the IP address 10.200.1.1/24.
The LAN (port3) interface has the IP address 10.0.1.254/24.


If the host 10.200.3.1 sends a TCP SYN packet on port 10443 to 10.200.1.10, what will the source address, destination address, and destination port of the packet be, after FortiGate forwards the packet to the destination?

• A.10.200.3.1, 10.0.1.10, and 443, respectively
• B.10.0.1.254, 10.200.1.10, and 443, respectively
• C.10.0.1.254, 10.0.1.10, and 443, respectively
• D.10.0.1.254, 10.0.1.10, and 10443, respectively

You have enabled logging on a FortiGate device for event logs and all security logs, and you have set up logging to use the FortiGate local disk.
What is the default behavior when the local disk is full?

• A.Logs are overwritten and the only warning is issued when log disk use reaches the threshold of 95%.
• B.No new log is recorded after the warning is issued when log disk use reaches the threshold of 95%.
• C.Logs are overwritten and the first warning is issued when log disk use reaches the threshold of 75%.
• D.No new log is recorded until you manually clear logs from the local disk.
