When a virtual server has an HTTP profile with compression enabled, which traffic is compressed by the BIG-IP?

• A.all sever-sid traffic for that cirtual srver
• B.selected traffic from the pool member to the BIG-IP
• C.selected traffic from the BIG-IP to the client
• D.all client-side traffic for that virtual server

What is the expected difference between two source address persistence profiles if profile A has a mask of 255.255.255.0 and profile B has a mask of 255.255.0.0?

• A.Profile A will have more clients matching existing persistence records.
• B.Profile B will have fewer persistence records for the sane client base.
• C.Profile B has a greater potential number of persistence records.
• D.There are no detectable differences.

A BIG-IP has the following objects configured: A SNAT pool with 2 members:
150.10.33.33 and 10.10.1.33 A load-balancing pool with 5 members:
10.10.1.1-10.10.1.5:80
The BIG-IP has two self-IP addresses: 150.10.10.10 and 10.10.1.10 A virtual server at 150.10.30.30:80 that is associated with both the SNAT pool and the load-balancing pool. If a client at IP address 200.10.10.10 initiates a connection to the virtual server, what will the source IP address be in the packets sent to the chosen pool member?

• A.200.10.10.10
• B.150.10.33.33
• C.10.10.1.33
• D.10.10.1.10
• E.It could be any of the addresses of the members of the load-balancing pool.
• F.150.10.30.30

An LTM has the 3 virtual servers, a SNAT, four self IP addresses defined and the networks shown in the exhibit. Selected options for each object are shown below. Settings not shown are at their defaults. VirtualServerl Destination: 10.10.2.102:80 netmask 255.255.255.255 Pool: Pool with 3 members in the 172.16/16 network VirtualServer2 Destination: 10.10.2.102:* netmask 255.255.255.255 Pool: Pool with 3 members in the 192.168/16 network VirtualServer3 Destination: 10.10.2.0:80 netmask 255.255.255.0 Type: IP Forwarding SNAT1 Source IP: All Addresses SNATAddress: SNAT Pool with 2 members- 172.16.20.50 and 192.168.10.50 Self IPs 192.168.1.1; 172.16.1.1; 10.10.2.1; 10.10.1.1 A connection attempt is made with a source IP and port of 10.20.100.50:2222 and a destination IP and port of 10.10.2.10:80. When the request is processed, what will be the destination IP address?

• A.The request will be dropped.
• B.Destination IP: 10.10.2.10
• C.Destination IP: pool member in the 192.168/16 network.
• D.Destination IP: pool member in the 172.16/16 network

How is traffic flow through transparent virtual servers different from typical virtual servers?

• A.the value in the tcp acknowledgement field
• B.any bytes within the initial client request packet
• C.an IP address
• D.any text string within a cookie
