A router receives a packet on interface 172.16.45.66/26. The source IP of the packet is
172.16.45.126/26 and the destination is 172.16.46.191/26. How will the router handle the packet?

• A.The destination is a host on another subnet, so the router will not forward the packet.
• B.The destination is a host on the same subnet, so the router will forward the packet.
• C.The destination is a network address, so the router will forward the packet.
• D.The destination is a broadcast address, so the router will not forward the packet.

According to the information provided in the exhibit, from where was the currently running version of IOS loaded?

• A.ROM
• B.NVRAM
• C.TFTP server
• D.flash

A receiving host has failed to receive all of the segments that it should acknowledge. What can the host do to improve the reliability of this communication session?

• A.obtain a new IP address from the DHCP server
• B.start a new session using UDP
• C.decrease the window size
• D.use a different source port for the session
• E.decrease the sequence number

Which IOS user EXEC command will allow a network technician to determine which router in the path to an unreachable network host should be examined more closely for the cause of the network failure?

• A.Router> telnet
• B.Router> show ip route
• C.Router> show interface
• D.Router> ping
• E.Router> trace
• F.Router> show cdp neighbors

A network administrator is connecting PC hosts A and B directly through their Ethernet interfaces as shown in the graphic. Ping attempts between the hosts are unsuccessful.
What can be done to provide connectivity between the hosts? (Choose two.)

• A.A rollover cable should be used in place of the straight-through cable
• B.A crossover cable should be used in place of the straight-through cable.
• C.A default gateway needs to be set on each host.
• D.The subnet masks should be set to 255.255.255.0.
• E.The subnet masks should be set to 255.255.255.192.
• F.The hosts must be reconfigured to use private IP addresses for direct connections of this type.
