During a VHT Transmit Beamforming sounding exchange, the beamformee transmits a Compressed Beamforming frame to the beamformer. What is communicated within this Compressed Beamforming frame?

• A.Beamforming Matrix
• B.Beamformee Matrix
• C.Feedback Matrix
• D.Steering Matrix

Given: Protocol analyzer often have useful graphical dashboards providing information about the health and operations of the WLAN.
What is a valid use of a graph showing the Top APs Based on Active Associations?

• A.Discovering the total number of client STAs on your network
• B.Evaluating the capacity handling on a specific channel
• C.Ensuring compliance with corporate security policies
• D.Locating overloaded APs

When performing protocol analysis, you notice a high number of RTS/CTS frames being transmitted on an HT network. You suspect this may be due to HT protection mechanisms.
Where in the Beacon frame would you look to determine which one of the four HT protection modes the AP is operating in?

• A.Non-HT Present Element
• B.HT Protection Element
• C.HT Operation Element
• D.HT Information Element

You are troubleshooting VoIP WLAN issues. When performing a PING to a remote device that would be involved in a call link, you see that the time value averages 220 milliseconds.
How much extra delay beyond that recommend for VoIP links is in this link?

• A.There is 80 milliseconds more delay than recommended
• B.There is 70 milliseconds more delay than recommended
• C.There is not enough information because the PING command give round-trip-times
• D.There is no extra delay beyond that recommended, instead there is 80 milliseconds less

Given: Before installing a Wi-Fi network, ABC Company performed a spectrum analysis looking for problems. The 2.4 GHz RF spectrum looked like Image-A. After installing an ERP WLAN, ABC Company performed another spectrum analysis during business hours. The 2.4 GHz RF spectrum then looked like Image-B close to an AP on channel 1.

Now the 2.4 GHz RF spectrum looks like Image-C and access points and clients can no longer communicate on channel 1. What is happening on channel 1?

• A.A high-power, narrowband RF interference source on channel 1 is causing the CCA energydetects(ED) function on 802.11 devices to indicate a busy medium because the signal source is above the ED threshold.
• B.The shape of the signals in images B and C indicates that a licensed user in this frequency range has enabled the "guard bands" in an effort to restrict local interference with other systems.
• C.Stronger transmissions from licensed 2.4 GHz users, such as HAM operators, are compressing the transmissions from the channel 1 access points into the lower portion of the band.
• D.The access point's antenna connectors have been tampered with, causing "spike and shear" RF transmissions that are not compatible with the OFDM PHY format. For that reason, client devices cannot receive the AP's transmissions without error.
• E.Detection of a DFS radar event has discontinued 802.11 operation on channel 1, but the access point's Channel Switch Announcement frame cannot be sent due to the presence of radar.
