Exhibit.

The building label shown is a single piece of annotative text with two annotative scales assigned to it (1: 50 and 1100) The current drawing scale is set to 1:50.
The 1:100 scale label must be moved outside the building and the 1:50 scale label must remain inside the building, as shown on the right in the exhibit How should the label location be modified?

• A.Leave the drawing scale set to 1 50 and then grip edit the text label
• B.Set the drawing scale to 1 100 and then grip edit the text label
• C.Set the drawing scale to 1 100 and then use the MOVE command
• D.Leave the drawing scale set to 1 50 and then use the MOVE command

Refer to exhibit.

A CAN designer is creating a tour-lane running track the outside lane is a polyline on the Track layer. The inside are to be placed on the current layer LANES.
Wlik.li options should the designer use with the OFFSET command at an offset distance of 10 to create the ruining track?

• A.Select the Layer option/Source with a distance of 10 and Multiple.
• B.Select the Through option and Multiple
• C.Select the Through option with a distance of 10 and Multiple
• D.Select the Layer option/Current with a distance of 10 and Multiple

You have a simple polyline selected that consists of li Select whether each statement is True or False.

正解：

* FalseYou cannot convert an arc to a line by hovering over the center grip of the arc segment. You need to convert the arc to a polyline first, then use the FLATTEN command, and answer YES to remove hidden lines. Then you can explode the polyline to get line segments.
https://forums.autodesk.com/t5/autocad-forum/autocad-is-it-possible-to-convert-an-arc-to-a-segemented-li
* Falseyou can edit the polyline width by hovering over certain grips if they are vertex grips or midpoint grips. However, if they are arc segment grips, you cannot edit the width by hovering over them1.
Therefore, the statement is false.
https://knowledge.autodesk.com/support/autocad/learn-explore/caas/CloudHelp/cloudhelp/2015/ENU/Auto
* Falseyou can add a new vertex by hovering over certain grips if they are edge grips or midpoint grips. However, if they are vertex grips or arc segment grips, you cannot add a new vertex by hovering over them2. Therefore, the statement is false.

A CAD designer adds the Annotation Scale tool to the status bar During their work, the designer notices that it Is no longer visible What is causing, this issued?

• A.The designer's user interface is locked
• B.The geometry Is outside of the drawing limits
• C.The designer Is in model space
• D.The designer is in paper space.

You have the office arrangement shown in exhibit 1. (Refer to the exhibit 1 tab.)

You need a mirror line to create the right-hand office arrangement shown in exhibit 2. (Refer to the exhibit 2 tab.)

Which tool would you use to make sure the mirror line is centered between the two wall lines without adding additional linework?

• A.Intersection (INT)
• B.Endpoint (END)
• C.Mid Between Two Points (M2P)
• D.Midpoint (MID)
