6101.1 試験問題を無料オンラインアクセス

The exhibit indicates the two show commands from an edge Ethernet Routing Switch (ERS) 5520-24T-PWR an untagged frame arrives on port 10.which is configured as an access port
To which VLAN will the packet be forwarded?

• A.All untagged packets will be placed in the default VLAN (VLAN 1).
• B.All untagged packets will be placed in VLAN 311
• C.All untagged packets will he discarded.
• D.All untagged packets will be placed in VLAN 31?

The goal of the Converged Campus architecture is to provide a highly reliable infrastructure with sub second failover preventing any interruption of traffic on the network.
HMD primary benefits of this design goal? (Choose two)

• A.in the event of a failure, no loss of connectivity or application availability will be experienced by the end user
• B.This design goal provides numerous connectivity options including Asynchronous Transfer Mode (ATM), Packet over SONET (POS) and 10 gigabit Ethernet.
• C.The ability to provide hitless software upgrades for the core of the network.
• D.The architecture provides high performance Layer 3 switching, resiliency, security, and services.

Confirm that RSMLT will work on a set of VLANs. Which network design aspect should be considered?

• A.RSMLT is enabled on the VLAN group.
• B.RSMLT is enabled on each SMLT VLAN on which the function is required
• C.RSMLT is enabled on all SMLT VLANs.
• D.Router 1 always owns the network.

An Ethernet Routing Switch (ERS) 5000 Series Release 6.2 Is installed in environment.
TO UPGRADE TO A version that includes new features, which statement about licenses is true?

• A.licenses are associated with software releases, not license feature levels.
• B.Remove the old license from the switch and load a new license file
• C.Automatic Unit Replacement (AUR) automatically updates software feature license for any replacement stack unit, except the base unit.
• D.The features designated to the license level are available as soon as the upgrade is completed.

With release 4.0 or higher software on the Ethernet routing switch (ERS) 8300, an advanced routing license is required to enable certain features.
Which two statements ant true about the Advanced Routing License process and supported features for the ERS 8300? (Choose two.)

• A.the Advanced Routing License supports QoS, SMLT, VRRP and OSPF
• B.To protect against security breaches, the ERS 8300 allows only a primary path for the license file
• C.To protect against system flash failure, the ERS 8300 allows a primary, secondary, and tertiary path for the license file.
• D.the Advanced Routing License supports SMLT, VRRP, OSPF, PIM-SM. and SLPP
